ASCO - 2/2 Steam valve 3/8\"-3/4\"

Normally closed

Media temperature up to +180 °C

Working pressure 0 to 9 bar steam

Housing in brass

£0.00
Tax included
Quantity :
Ask a Question


General Data
Connection 3/8 BSP
Flow factor / flow coefficient 2,4
IP class IP65


Material Data
Material body Brass
Material of seals PTFE
Material seat Brass


Temperature Data
Temperature of media from -20 °C
Temperature of media to 184 °C


Additional Data
Pressure max 10 bar
Close delay 75 ms
Weight 1.3 kg
Power consumption 16.7 W
Throughput 16 mm
Type of valve Solenoid valve
Response time off 100 ms
Voltage AC 230 V
Temperature operational min -20 °C
Temperature operational max 40 °C
Material coil Epoxy
Differential pressure max 9 bar
Differential pressure min 0 bar
Flow max 40 l/min
Function 1 2/2
Function 2 Normally Closed
Material flask Brass
Material piston ring PTFE flask filled
Material plunger Stainless steel
Material short-circuit ring Copper
Material spring Stainless steel
