Angle Seat And Piston Valves

Zeus series Angle seat valve

Bronze Angle seat valve from Omal (Zeus) comes with threaded valve ends, as per ISO 228/1 and ISO 7/1 – other types available on request. Available from sizes 3/8" - 2" in Double Acting or Spring Return Normally Closed from above and below the plug or Spring Return Normally Open from below the plug. ATEX available on request.

Sizes 3/8" to 2"

Pressure range 0 to 16 / 25 bar

Temperature range -10°C to +60°C

ATEX available on request

Double acting or spring return

Normally closed W

Working pressure 0 to 24 bar

Housing in brass or stainless

Normally closed, normally open

Working pressure 0 to 40 bar

For temperatures up to +250 °C

For viscosity up to 5,000 cSt

Normally closed, normally open

Extremely compact version

Working pressure 0 bar to 16 bar

Housing in stainless

Universal

Working pressure 0 to 40 bar

For temperatures up to +250 °C

For viscosity up to 5,000 cSt
