Suco - 0151 Vacuum Switch

Brass body

The 0151 series vacuum switch is a brass bodied switch from SUCO for vacuum applicatiosn. Offering a maximum voltage of 42V with normally open or normally closed contacts housed in a hex 24 brass body. The switch point is very stable even after a long period of time and high load and also adjustable on site and can come pre-set.

Common applications include water, medical, air and chemical.

Up to 42 V

Spade or screw terminals

Adjustment range of 200 mbar to 950 mbar (relative)

Normally open or Normally closed

Over pressure safety of 35 bar

£0.00
Tax included
Quantity :
Ask a Question

Adjustment range max 0.95 bar
Adjustment range min 0.2 bar
Approvals RoHS II
Contact rating max 4 A
Deviation max ±100mbar
Electrical connection Spade (AMP 6,3x0,8 mm)
Function Normally Closed (SPST)
IP class IP00
Material membrane FKM
Material of body Brass
Material of wetted parts FKM, Brass
Max switching frequency/min 200
Operating range max 950 mbar
Operating range min 200 mbar
Process connection G1/8 female
Temperature ambient from -20 °C
Temperature ambient to 80 °C
Temperature of media from -15 °C
Temperature of media to 120 °C
Weight 140 g
Voltage ac/dc max 42 V
Voltage ac/dc min 10 V
