Honsberg - LABO XF Series Flow Meter

Dynamic diaphragm (flap)

Model XF is a compact flow sensor in PPS plastic or stainless for water applications. Measurement takes place via a spring mounted metal plate which gives a rapid response time, low pressure drop, and high accuracy. The design with no moving parts makes it suitable for applications where this is a requirement. XF can be simply combined with Honsberg's Omni- or Flex technology.

For liquids up to 16 bar

Flow from 1 l/min. to 80 l/min.

Connection from 1/4" to 3/4"

Housing in PPS or stainless
£0.00
Tax included
Quantity :
Ask a Question

Model XF is a compact flow sensor in PPS plastic or stainless for water applications. Measurement takes place via a spring mounted metal plate which gives a rapid response time, low pressure drop, and high accuracy. The design with no moving parts makes it suitable for applications where this is a requirement. XF can be simply combined with Honsberg's Omni- or Flex technology.

Accuracy ± 3% of the measured value, but at least 0.25 l / min
Connection type Internal thread G ¼ "
Electrical connection Plug M12x1, 4-pole
Flow max 120 l/min
Flow range max 15 l/min
Flow range min 1 l/min
Function Dynamic membrane
IP class IP67
Load max 100 mA
Material of body PPS
Material of connection Nickel-plated brass
Material of seals Viton
Material tinplate Stainless steel 1.4031k
Power consumption 20 mA
Pressure drop Approximately 0.5 bar at maximum flow
Pressure range max 16 bar
Signal outputs 4-20 mA
Temperature of media from 0 °C
Temperature of media to 70 °C
Type of flow component Flow Measuring
Weight 0.35 kg
Viscosity max 1 cSt
Voltage dc max 30 V
Voltage dc min 10 V
